位置:首页 > 品牌 > SUPELCO > TLC Silica gel 60 with concentrating zone 10 x 2.5 cm

TLC Silica gel 60 with concentrating zone 10 x 2.5 cm

品牌
Supelco
货号
1.11844
规格纯度
pkg of 50 plates, plate L × W 20 cm × 10 cm, glass support
参考价格
5518.24 *本价格含增值税费
促销
服务
  • 原厂保证
  • 包邮
  • 增值税票
数量
-+
产品名称:
TLC Silica gel 60 with concentrating zone 10 x 2.5 cm
产品介绍:

产品说明

一般描述

50 Glass plates 10 x 20 cm
These plates allow users to quickly and easily apply any kind of sample, even large volumes of diluted samples. Our concentrating zone plates are based on different adsorption properties of two adsorbents. The first is a large pore concentrating adsorbent where the samples are applied; the second is a selective layer for separation. Regardless of the spots’ shape, size, or position, the sample always concentrates as a narrow band where the two adsorbents overlap and where the separation starts. These plates allow users to quickly and easily apply any kind of sample, even large volumes of diluted samples.

联系

Replaces: 11844-6; 11844

分析说明

Specific surface area (according to BET; 5-Pt. measurement): 480 - 540 m²/g
Pore volume (N₂-isotherm): 0.74 - 0.84 ml/g
d 50 (laser diffraction, size distribution): 10 - 12 µm
Layer thickness: 170 - 250 µm
Deviation of layer thickness per plate: ≤ 50 µm
layer thickness concentrating zone: 90 - 130 µm
Fluctuation in the thickness of the concentration zone: ≤ 35 µm
Chromatographic testing:
colour test
hRf-values
- bleu vif organol, colour test, lipophile:
15 - 21
- Ceres Black G, colour test, lipophile: 36 - 42
- ceres Violet brn, colour test, lipophile: 51 - 58
Typical value determined on a conditioned plate
Eluent: toluene (45% rel. humidity)

产品性质

物料glass support
silica gel 60 matrix
质量水平100
特点binder Organic Polymer
fluorescent indicator: no
包装pkg of 50 plates
technique(s)thin layer chromatography (TLC): suitable
层厚度250 μm
板长度 × 宽度20 cm × 10 cm
粒径10-12 μm
孔径60 Å medium pore diameter
储存温度2-30℃
