产品说明

一般描述

The Perfect Combination of Low Bleed, Thermal Stability, and Easy Puncturability!

Molded Thermogreen LB-2 septa are manufactured from high quality, low bleed material using the same exclusive LB-2 rubber formulation that chromatographers are accustomed to using. The difference is that molded septa, unlike traditional die-cut septa, offer easier installation and better sealing inside the injection port. This is because our liquid injection molding process ensures that every septum conforms to the same shape with crisp, clean sides. This is an improvement over a die-cutting process where septa can become cupped and/or distorted when the cutting surface becomes dull.

The useable inlet temperature range of 100-350 ℃ is adequate for most GC applications. Don′t be fooled by other septa that advertise a maximum temperature of 400 ℃! Tto make septa with high thermal limits, they must be made stiffer, resulting in septa that are harder to pierce and easier to core! Our molded Thermogreen LB-2 septa offer the perfect combination of low bleed, thermal stability, and easy puncturability.

• Rubber formulation exclusive to Supelco
• Strict tolerances (diameter, thickness, injection hole) due to constant dimension of the mold itself
• Ultra low bleed over a wide range of inlet temperatures (100 ℃ to 350 ℃)
• No foreign substances/powders (which could contaminate the inlet) are used during manufacturing
• Fully tested for bleed and contamination
• Already conditioned, ready to use
• Ideal for use with low bleed GC-MS columns

其他说明

The injection hole helps guide the syringe needle to puncture the same location every injection, resulting in two benefits:

• Minimal coring leading to long life
• Less septum fragments that contaminate the inlet liner

Their high puncture tolerance makes these septa ideal for use with autosampler injections, manual injections, and/or SPME applications.

法律信息

Thermogreen is a registered trademark of sigma-aldrich Co. LLC

基本信息

NACRES

SB.54

产品性质

包装	pkg of 50 ea
直径	11 mm

安全信息

储存分类代码	13 - Non Combustible Solids
WGK	WGK 3
闪点(F)	Not applicable
闪点(C)	Not applicable
