产品说明
一般描述
25 Aluminium sheets 20 x 20 cm
Precoated Kieselguhr or mixed Silica gel/Kieselguhr plates are only of small importance nowadays. Kieselguhr layers are used like cellulose layers for the TLC separation of polar and moderately polar substances. Polyamide, on the other hand , is used for the separation of flavonoids and other phenolic substances.
联系
Replaces: 5568-7; 5568
分析说明
Layer thickness: 170 - 220 µm
Deviation of layer thickness per plate: ≤ 30 µm
Chromatographic testing:
amino acid test
hRf-values
- β-alanine, short-time test:
25 - 30
- L-alanine, amino acid test: 45 - 55
- DL-Valin, amino acid test: 75 - 85
- L-leucine, amino acid test: 85 - 95
Typical value determined on a sheet
Eluent: n- propanol/ water (80/20 v/v)
产品性质
| 物料 | aluminum support silica gel 60 matrix |
| 质量水平 | 100 |
| 特点 | binder Organic Polymer fluorescent indicator |
| 包装 | pkg of 25 sheets |
| technique(s) | thin layer chromatography (TLC): suitable |
| 层厚度 | 200 μm |
| 薄片长度 × 宽度 | 20 cm × 20 cm |
| 粒径 | 10-12 μm |
| 储存温度 | 2-30℃ |
