产品说明
一般描述
PLC plates allow users to separate samples that vary greatly in size – from grams down to milligrams. Available with or without a fluorescence indicator, PLC plates has 1 mm thickness. They also use our same proven silica-binder technology as in analytical TLC plates. To isolate the substance by extraction, users can simply scrape the spot from the layer.
15 Glass plates 20 x 20 cm
联系
Replaces: 13895-7; 13895
分析说明
Layer thickness: 800 - 1200 µm
Deviation of layer thickness per plate: ≤ 250 µm
Chromatographic testing:
colour test
hRf-values
- bleu vif organol, colour test, lipophile:
20 - 30
- Ceres Black G, colour test, lipophile: 40 - 50
- ceres Violet brn, colour test, lipophile: 60 - 70
Typical value determined on a conditioned plate
Eluent: toluene (45% rel. humidity)
产品性质
| 物料 | glass support silica gel 60 matrix |
| 质量水平 | 100 |
| 特点 | binder Organic Polymer fluorescent indicator |
| 包装 | pkg of 15 plates |
| technique(s) | thin layer chromatography (TLC): suitable |
| 层厚度 | 1 mm |
| 板长度 × 宽度 | 20 cm × 20 cm |
| 粒径 | 20-40 μm |
| 孔径 | 60 Å medium pore diameter |
| 储存温度 | 2-30℃ |
